Product Specifications
|
No. of inputs
|
6
|
|
Input sampling
|
10s/6ch, max
|
|
Type of input
|
±10mV, 0-20mV, 0-50mV, ±1V, 1-5V
|
|
Direct ourrent
|
4-20mA
|
|
Thermocouple
|
K, T, J, E,B,S,R,G,C,N,PR40-20, PLII, L, Au-Fe
|
|
RTD
|
Pt100, Pt50, JPt100
|
|
Accuracy
|
±0.2%±1 digit max. for Digital indicator/printing
|
|
Noise reduction
|
NMRR: 60dB min.
|
|
CMRR
|
140dB min.
|
|
Isolation resistance
|
Each terminals/ground: 500VDC, 20MΩ min.
|
|
Dielectric strength
|
Power input terminal/ground: 1.5kVAC, 1 minute
|
|
Input terminal/ground
|
0.5kVAC, 1 minute
|
|
Nos. of relay outputs
|
6 outs (Form a contacts; Built-in option)
|
|
Capacity
|
30VDC 3A Max. Loaded
|
|
Interface
|
RS-232C (Standard), RS-485
|
|
Rated power voltage
|
100-240VAC (50/60Hz)
|
|
Power consumption
|
25VA max.
|
|
Mounting/housing
|
Panel mounting/Front panel: Dust-proof,Water-proof (IP-65)
|
|
Dimension
|
144(W) x 144(H) x 150(D) mm
|
|
Weight
|
1.5kg
|
|
Allowable conditions
|
Temperature: 0-50°C, Humidity: 20-80%
|
Recording / Printing Performance
|
Recording
|
Raster-scan printing
|
|
Printing
|
Dotting with 6 color ribbon
|
|
Dot print interval
|
10.0s/6ch max.
|
|
Chart paper
|
Length 16m, Dotting width: 100mm
|
|
Chart speed
|
User-selective from 28 speed
|
|
In range
|
10-1500mm/hr
|
|
Printing color
|
Purple, Red, Green, Blue, Brown, Black
|
