| Power Supply: |
Dual-mode: USB powered / Rechargeable Li-ion battery |
| USB/ Battery: 3-month life @10 min. interval |
| Interface: |
micro-USB/ USB |
| Communication Protocol: |
Wi-Fi 2.4G/ HTTP/ TCP/ UDP Broadcast |
| Software: |
Mobile App: XH Logger, iOS and Android system |
| |
| Cloud: AWSIOT Webpage online, working with Windows 10 and the above |
| USB Voltage (@500mA): |
Minimum |
Typical |
Maximum |
| 4.5Vdc |
5Vdc |
5.5Vdc |
| Sensor Type: |
External sensor probe for temperature and humidity |
| Sensor Response Time: |
Temperature > 2 sec |
| Humidity: 8 sec |
| Logging Interval: |
User configurable from10 minutes to 24 hours |
| Temp. display resolution: |
0.1 °C/ 0.1°F/ 0.1% |
| LCD Operating Range: |
-20°C (-4°F) ~60°C (122°F) |
| Accuracy: |
Temp. |
0°C ~ 50°C (±0.3°C), Others ±0.5°C |
| Humditiy |
20%~80%@25°C(±3%RH), Others ±5%RH |
| Time Accuracy: |
NTP (Network Time Protocol) |
| Alarm Configuration: |
High High, High, Low, Low Low |
| Calibration: |
Calibration is completed by the original manufacturer. |
| Internal Memory: |
Each file can contain maximum79,872 logs, keeping logging and overwritten |
| Pre-program: |
User Programmable |
| Start Option: |
Push button, Immediate, At time, Cloud controlled (App/ Webpage account) |
| Auto Overwritten: |
Supported |
| Start Delay: |
Supported, 1 min to 23 hr and 59 min |
| Stop Option: |
Push button; At Time |
| Default File Format: |
PDF |
| Data Export: |
PDF, Excel |
| Security Lock: |
Password Protected |
| Housing: |
PC540 PC+ABS |
| IP Rating: |
IP63 |
| Dimensions, XH Case: |
65.1 x 70 x 23.25mm |
| Weight: |
130 g (Battery and 1M external sensor included) |
| XH Warranty: |
12 months, battery not included |
| Battery Type: |
3.7V/ 1500mA Li-ion, rechargeable Li battery |
| Total Charging Time: |
Battery charging time: when using charging power source DC4.25V/1A (≥1A), from 0 to 100% fully charged around 4 hours |
| Temperature: |
Temperature range during battery charging: |
| 10°C (50°F) ~45°C (113°F) |
| Charging Cycle: |
Battery charging cycle: 2 to 3 months maximum with fully charged and normal usage |
| Battery Life: |
1 year-life @ 10 min. log interval, 1 year-life from the battery original factory |
| 3-month lasting after battery full charged with normal usageBattery |
| Battery Warranty: |
The battery warranty length is limited as consumable item. Keep the battery to operate, to store, to charge, to discharge in the specific temperature and humidity. |
| Keep the battery to about 50%SOC when not in use and recharge again within 6 month after received. |
| Accuracy Certificate: |
Optional |
| Safety: |
CE, RoHS, FCC (Class B) |
